Name: SS304L 8-5/8" Slot 40 Water Well Screen For Sand Control In Water Wells
Brand: Anping County Hengyuan Hardware Netting Industry Product Co.,Ltd.
SKU: 8-5/8"
Price: 200.00 USD
Availability: InStock

Dom > Produkty > Ekran studni wodnej >

SS304L 8-5/8" Slot 40 Water Well Screen For Sand Control In Water Wells

Sand Control Water Well Screen

SS304L Water Well Screen

8-5/8" Water Well Screen

Miejsce pochodzenia:

Hengshui, Hebei, Chiny

Nazwa handlowa:

Heng Yuan

Orzecznictwo:

ISO9000

Numer modelu:

8-5/8"

Skontaktuj się z nami

Poprosić o wycenę

Szczegóły Produktu

nazwisko:

Ekran studni

Materiał:

Stal nierdzewna 304L

Średnica:

219 mm

Długość:

5800 mm

Rozmiar gniazda:

1,0 mm

Owiń drut:

3,0 × 4,6 mm

Pręt podtrzymujący:

ø4,0 mm

NIE. z pręta:

48 NIE

Zakończenie połączenia:

API STC Gwint

Waga:

110 kg/kawałek

Pakiet:

folia z tworzywa sztucznego

Użycie:

W studniach wodnych do kontroli piasku

Produkty powiązane

wideo

SS304L 12-3/4" Slot 40 Water Well Screen For Irrigation

Uzyskaj najlepszą cenę

wideo

Stainless Steel 304L Rod Based Continuous Slot Wedge Wire Screen

Uzyskaj najlepszą cenę

wideo

SS304 Vee Wire Water Well Screen Non Clogging Long Lasting Performance

Uzyskaj najlepszą cenę

wideo

Niski poziom węgla ocynkowany wodociąg

Uzyskaj najlepszą cenę

Skontaktuj się z nami

86-318-7565918

hengyuan1@aphywire.com

86-318-7565919

Skontaktuj się teraz

Opis produktu

8-5/8" Slot 40 Water Well Screen For Sand Control In Water Wells

Commonly referred to as continuous slot or wire wrap screen, continuous slot water well screen was originally developed to overcome problems associated with cable tool wells drilled in fine grained, uniform sands in the North Central United States.

These wells were typically completed in relatively shallow, thin aquifers that were very prolific in terms of water production.

Continuous wire wrap screen are very effective in wells of this type since they can be manufactured with very small slot size and yet still maintain the necessary open area to minimize frictional head loss.

Water Well Screen Regular Specifications:

Name:Continuous Slot Rod Based Water Well Screen,Oil Well Sand Screen,Water Well Screen, Wedge wire screen,Screen tube,Wound screen,Sand control screen, Wedge wire screen pipe, Rotary filter drum,Oil screen.
Material: Stainless steel 202,304,304L,316L,Non-magnetic Stainless steel,Low carbon galvanized etc.
Diameter: 3", 4", 6", 8", 10", 12", 14", 16", 18" etc.
Slot: From 0.1-100mm (Normal slot 0.5mm, 0.63mm, 0.75mm, 1.0mm, 1.5mm, Pls refer to below table)
Length: From 100-6000mm (Normal length is 2.9m/3m and 5.8m/6m, to fit container)
Wrap wire:23.5mm,2.23.5mm,34.6mm,35mm,36mm,36.5mm,3.26mm,47mm etc.
Support rod:ø3.0-ø6.0mm round wire, Also can be Vee-shaped wire.
Ends:Welded rings/Plain beveled ends,Male/female threaded,Flange etc.
Use:Water Well,Oil Wells,Waste Water Treatment,Water supply systems,Coal & Mine, Food Processors & Beverage Screens,Environmental protection,Refining & Petrochemical,Architecture & Construction etc.
Sizes (inch)	OD (mm)	Slot (mm)	Length (m)	Tenslie Strength	Collapse Strength	Wrap wire Vee-shaped wire(mm)	Support rod Round wire(mm)
3-1/2	88.9	1.0	2.9	＞22	10.2	2.03.5(Widthheight)	ø3.8MM×22
4-1/2	114.3	1.0	2.9	＞28	11.5	2.03.5(Widthheight)	ø3.8MM×22
6-5/8	168.3	0.75	5.8	＞40	12.8	2.03.5(Widthheight)	ø3.8MM×32
6-5/8	168.3	1.0	5.8	＞33	12.8	2.23.5(Widthheight)	ø3.8MM×32
6-5/8	168.3	0.63	5.8	＞83	45	3.06.0(Widthheight)	ø6.0MM×32
8-5/8	219.1	1.0	5.8	＞34	21.9	2.23.5(Widthheight)	ø3.8MM×48
8-5/8	219.1	1.0	5.8	＞50	38.2	3.04.6(Widthheight)	ø4.0MM×48
8-5/8	219.1	1.0	5.8	＞60	46	3.06.0(Widthheight)	ø5.0MM×48
10-3/4	273.1	0.75	5.8	＞50	32.9	2.23.5(Widthheight)	ø4.0MM×55
10-3/4	273.1	1.0	5.8	＞60	39.5	3.04.6(Widthheight)	ø4.8MM×55
10-3/4	273.1	1.0	5.8	＞100	48	3.26.0(Widthheight)	ø5.0MM×55
12-3/4	323.9	1.0	5.8	＞120	37.2	3.05.0(Widthheight)	ø4.0MM×56
14	355.6	1.0	2.9	＞80	37.8	3.05.5(Widthheight)	ø4.0MM×59
16	426	1.0	2.9	＞80	37.5	3.05.5(Widthheight)	ø4.0MM×64

Special specification can be made according to your need !

Water Well Screen Use:

Water Well,

Food &Beverage Screens,

Pharmaceutical & Biological industries,

Refining & Petrochemical,

Water Treatment & Liquid / Solids Separation,

Mineral & Aggregate Processing,

Pulp & Paper Screens.
